SY Multicore Colour Coded

Code: F1281

  • Versatile, flexible control cable
  • Wide range of sizes and core counts
  • Galvanised steel braid for mechanical protection
  • Highly flexible through use of use of fine copper wire stranding and pliable PVC compounds
Where mechanical protection is called for on a flexible cable, SY cable is a popular choice. The tough, flexible, clear outer sheath provides excellent abrasion and oil resistance. SY cables are suitable as a supply or control cable for motors, plant, machinery and many other applications.

Image representative of product style, product supplied may vary.
Fine copper wire strands to IEC 60228 Class 5.
Black PVC insulation with white number coded cores
Cables with more than 2 cores include a green/yellow earth, cores twisted together.
Grey PVC inner sheath, steel wire braid, clear PVC outer sheath.
Voltage Rating:
Working: 300/500V
Test: 3000V
Temperature Rating:
Static: -20°C to +80°C
Flexing: -5°C to +70°C
Bending Radius:
Fixed: 10 x cable diameter
Flexing: 20 x cable diameter
Current Rating: Refer to IEE Regs Table 4F3A&B

Order by 4.30pm for delivery by

Code Description Armour No. Cores mm² Colour Sheath CPR Class Downloads
11000702C
2 x 0.75mm² SY PVC Steel Braided Multicore Clear
GSWB 2 0.75 Clear PVC - Get Quote
Description 2 x 0.75mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 2
mm² 0.75
Colour Clear
Sheath PVC
CPR Class -
11000703C-E00
3 x 0.75mm² SY PVC Steel Braided Multicore Clear
GSWB 3 0.75 Clear PVC Eca Get Quote
Description 3 x 0.75mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 3
mm² 0.75
Colour Clear
Sheath PVC
CPR Class Eca
11000704E
4 x 0.75mm² SY PVC Steel Braided Multicore Clear
GSWB 4 0.75 Clear PVC - Get Quote
Description 4 x 0.75mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 4
mm² 0.75
Colour Clear
Sheath PVC
CPR Class -
11000705E
5 x 0.75mm² SY PVC Steel Braided Multicore Clear
GSWB 5 0.75 Clear PVC - Get Quote
Description 5 x 0.75mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 5
mm² 0.75
Colour Clear
Sheath PVC
CPR Class -
11000707C
7 x 0.75mm² SY PVC Steel Braided Multicore Clear
GSWB 7 0.75 Clear PVC - Get Quote
Description 7 x 0.75mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 7
mm² 0.75
Colour Clear
Sheath PVC
CPR Class -
11000712C
12 x 0.75mm² SY PVC Steel Braided Multicore Clear
GSWB 12 0.75 Clear PVC - Get Quote
Description 12 x 0.75mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 12
mm² 0.75
Colour Clear
Sheath PVC
CPR Class -
11001002C
2 x 1.0mm² SY PVC Steel Braided Multicore Clear
GSWB 2 1 Clear PVC - Get Quote
Description 2 x 1.0mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 2
mm² 1
Colour Clear
Sheath PVC
CPR Class -
11001003C-E00
3 x 1.0mm² SY PVC Steel Braided Multicore Clear
GSWB 3 1 Clear PVC Eca Get Quote
Description 3 x 1.0mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 3
mm² 1
Colour Clear
Sheath PVC
CPR Class Eca
11001004E
4 x 1.0mm² SY PVC Steel Braided Multicore Clear
GSWB 4 1 Clear PVC - Get Quote
Description 4 x 1.0mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 4
mm² 1
Colour Clear
Sheath PVC
CPR Class -
11001005E
5 x 1.0mm² SY PVC Steel Braided Multicore Clear
GSWB 5 1 Clear PVC - Get Quote
Description 5 x 1.0mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 5
mm² 1
Colour Clear
Sheath PVC
CPR Class -
11001007C
7 x 1.0mm² SY PVC Steel Braided Multicore Clear
GSWB 7 1 Clear PVC - Get Quote
Description 7 x 1.0mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 7
mm² 1
Colour Clear
Sheath PVC
CPR Class -
11001012C
12 x 1.0mm² SY PVC Steel Braided Multicore Clear
GSWB 12 1 Clear PVC - Get Quote
Description 12 x 1.0mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 12
mm² 1
Colour Clear
Sheath PVC
CPR Class -
11001502C
2 x 1.5mm² SY PVC Steel Braided Multicore Clear
GSWB 2 1.5 Clear PVC - Get Quote
Description 2 x 1.5mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 2
mm² 1.5
Colour Clear
Sheath PVC
CPR Class -
11001503C
3 x 1.5mm² SY PVC Steel Braided Multicore Clear
GSWB 3 1.5 Clear PVC - Get Quote
Description 3 x 1.5mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 3
mm² 1.5
Colour Clear
Sheath PVC
CPR Class -
11001504E-E00
4 x 1.5mm² SY PVC Steel Braided Multicore Clear
GSWB 4 1.5 Clear PVC Eca Get Quote
Description 4 x 1.5mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 4
mm² 1.5
Colour Clear
Sheath PVC
CPR Class Eca
11001505E
5 x 1.5mm² SY PVC Steel Braided Multicore Clear
GSWB 5 1.5 Clear PVC - Get Quote
Description 5 x 1.5mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 5
mm² 1.5
Colour Clear
Sheath PVC
CPR Class -
11001507C
7 x 1.5mm² SY PVC Steel Braided Multicore Clear
GSWB 7 1.5 Clear PVC - Get Quote
Description 7 x 1.5mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 7
mm² 1.5
Colour Clear
Sheath PVC
CPR Class -
11001512C
12 x 1.5mm² SY PVC Steel Braided Multicore Clear
GSWB 12 1.5 Clear PVC - Get Quote
Description 12 x 1.5mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 12
mm² 1.5
Colour Clear
Sheath PVC
CPR Class -
11002502C
2 x 2.5mm² SY PVC Steel Braided Multicore Clear
GSWB 2 2.5 Clear PVC - Get Quote
Description 2 x 2.5mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 2
mm² 2.5
Colour Clear
Sheath PVC
CPR Class -
11002503C
3 x 2.5mm² SY PVC Steel Braided Multicore Clear
GSWB 3 2.5 Clear PVC - Get Quote
Description 3 x 2.5mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 3
mm² 2.5
Colour Clear
Sheath PVC
CPR Class -
11002504E
4 x 2.5mm² SY PVC Steel Braided Multicore Clear
GSWB 4 2.5 Clear PVC - Get Quote
Description 4 x 2.5mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 4
mm² 2.5
Colour Clear
Sheath PVC
CPR Class -
11002505E
5 x 2.5mm² SY PVC Steel Braided Multicore Clear
GSWB 5 2.5 Clear PVC - Get Quote
Description 5 x 2.5mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 5
mm² 2.5
Colour Clear
Sheath PVC
CPR Class -
11002507C
7 x 2.5mm² SY PVC Steel Braided Multicore Clear
GSWB 7 2.5 Clear PVC - Get Quote
Description 7 x 2.5mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 7
mm² 2.5
Colour Clear
Sheath PVC
CPR Class -
11002512C
12 x 2.5mm² SY PVC Steel Braided Multicore Clear
GSWB 12 2.5 Clear PVC - Get Quote
Description 12 x 2.5mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 12
mm² 2.5
Colour Clear
Sheath PVC
CPR Class -
11004003C
3 x 4.0mm² SY PVC Steel Braided Multicore Clear
GSWB 3 4 Clear PVC - Get Quote
Description 3 x 4.0mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 3
mm² 4
Colour Clear
Sheath PVC
CPR Class -
11004004E
4 x 4.0mm² SY PVC Steel Braided Multicore Clear
GSWB 4 4 Clear PVC - Get Quote
Description 4 x 4.0mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 4
mm² 4
Colour Clear
Sheath PVC
CPR Class -
11004005E
5 x 4.0mm² SY PVC Steel Braided Multicore Clear
GSWB 5 4 Clear PVC - Get Quote
Description 5 x 4.0mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 5
mm² 4
Colour Clear
Sheath PVC
CPR Class -
11004007C
7 x 4.0mm² SY PVC Steel Braided Multicore Clear
GSWB 7 4 Clear PVC - Get Quote
Description 7 x 4.0mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 7
mm² 4
Colour Clear
Sheath PVC
CPR Class -
11006003C
3 x 6.0mm² SY PVC Steel Braided Multicore Clear
GSWB 3 6 Clear PVC - Get Quote
Description 3 x 6.0mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 3
mm² 6
Colour Clear
Sheath PVC
CPR Class -
11006004E
4 x 6.0mm² SY PVC Steel Braided Multicore Clear
GSWB 4 6 Clear PVC - Get Quote
Description 4 x 6.0mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 4
mm² 6
Colour Clear
Sheath PVC
CPR Class -
11006005E
5 x 6.0mm² SY PVC Steel Braided Multicore Clear
GSWB 5 6 Clear PVC - Get Quote
Description 5 x 6.0mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 5
mm² 6
Colour Clear
Sheath PVC
CPR Class -
11006007C
7 x 6.0mm² SY PVC Steel Braided Multicore Clear
GSWB 7 6 Clear PVC - Get Quote
Description 7 x 6.0mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 7
mm² 6
Colour Clear
Sheath PVC
CPR Class -
11010003C
3 x 10mm² SY PVC Steel Braided Multicore Clear
GSWB 3 10 Clear PVC - Get Quote
Description 3 x 10mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 3
mm² 10
Colour Clear
Sheath PVC
CPR Class -
11010004E
4 x 10mm² SY PVC Steel Braided Multicore Clear
GSWB 4 10 Clear PVC - Get Quote
Description 4 x 10mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 4
mm² 10
Colour Clear
Sheath PVC
CPR Class -
11010005E
5 x 10mm² SY PVC Steel Braided Multicore Clear
GSWB 5 10 Clear PVC - Get Quote
Description 5 x 10mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 5
mm² 10
Colour Clear
Sheath PVC
CPR Class -
11016003C
3 x 16mm² SY PVC Steel Braided Multicore Clear
GSWB 3 16 Clear PVC - Get Quote
Description 3 x 16mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 3
mm² 16
Colour Clear
Sheath PVC
CPR Class -
11016004E
4 x 16mm² SY PVC Steel Braided Multicore Clear
GSWB 4 16 Clear PVC - Get Quote
Description 4 x 16mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 4
mm² 16
Colour Clear
Sheath PVC
CPR Class -
11016005E
5 x 16mm² SY PVC Steel Braided Multicore Clear
GSWB 5 16 Clear PVC - Get Quote
Description 5 x 16mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 5
mm² 16
Colour Clear
Sheath PVC
CPR Class -
11025003C
3 x 25mm² SY PVC Steel Braided Multicore Clear
GSWB 3 25 Clear PVC - Get Quote
Description 3 x 25mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 3
mm² 25
Colour Clear
Sheath PVC
CPR Class -
11025004E
4 x 25mm² SY PVC Steel Braided Multicore Clear
GSWB 4 25 Clear PVC - Get Quote
Description 4 x 25mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 4
mm² 25
Colour Clear
Sheath PVC
CPR Class -
11025005E
5 x 25mm² SY PVC Steel Braided Multicore Clear
GSWB 5 25 Clear PVC - Get Quote
Description 5 x 25mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 5
mm² 25
Colour Clear
Sheath PVC
CPR Class -
11035003C
3 x 35mm² SY PVC Steel Braided Multicore Clear
GSWB 3 35 Clear PVC - Get Quote
Description 3 x 35mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 3
mm² 35
Colour Clear
Sheath PVC
CPR Class -
11035004E
4 x 35mm² SY PVC Steel Braided Multicore Clear
GSWB 4 35 Clear PVC - Get Quote
Description 4 x 35mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 4
mm² 35
Colour Clear
Sheath PVC
CPR Class -
11035005E
5 x 35mm² SY PVC Steel Braided Multicore Clear
GSWB 5 35 Clear PVC - Get Quote
Description 5 x 35mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 5
mm² 35
Colour Clear
Sheath PVC
CPR Class -
11050003C
3 x 50mm² SY PVC Steel Braided Multicore Clear
GSWB 3 50 Clear PVC - Get Quote
Description 3 x 50mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 3
mm² 50
Colour Clear
Sheath PVC
CPR Class -
11050004E
4 x 50mm² SY PVC Steel Braided Multicore Clear
GSWB 4 50 Clear PVC - Get Quote
Description 4 x 50mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 4
mm² 50
Colour Clear
Sheath PVC
CPR Class -
11050005E
5 x 50mm² SY PVC Steel Braided Multicore Clear
GSWB 5 50 Clear PVC - Get Quote
Description 5 x 50mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 5
mm² 50
Colour Clear
Sheath PVC
CPR Class -
11070003C
3 x 70mm² SY PVC Steel Braided Multicore Clear
GSWB 3 70 Clear PVC - Get Quote
Description 3 x 70mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 3
mm² 70
Colour Clear
Sheath PVC
CPR Class -
11070004E
4 x 70mm² SY PVC Steel Braided Multicore Clear
GSWB 4 70 Clear PVC - Get Quote
Description 4 x 70mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 4
mm² 70
Colour Clear
Sheath PVC
CPR Class -
11070005E
5 x 70mm² SY PVC Steel Braided Multicore Clear
GSWB 5 70 Clear PVC - Get Quote
Description 5 x 70mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 5
mm² 70
Colour Clear
Sheath PVC
CPR Class -
11095003C
3 x 95mm² SY PVC Steel Braided Multicore Clear
GSWB 3 95 Clear PVC - Get Quote
Description 3 x 95mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 3
mm² 95
Colour Clear
Sheath PVC
CPR Class -
11095004E
4 x 95mm² SY PVC Steel Braided Multicore Clear
GSWB 4 95 Clear PVC - Get Quote
Description 4 x 95mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 4
mm² 95
Colour Clear
Sheath PVC
CPR Class -
11095005E
5 x 95mm² SY PVC Steel Braided Multicore Clear
GSWB 5 95 Clear PVC - Get Quote
Description 5 x 95mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 5
mm² 95
Colour Clear
Sheath PVC
CPR Class -
11120004E
4 x 120mm² SY PVC Steel Braided Multicore Clear
GSWB 4 120 Clear PVC - Get Quote
Description 4 x 120mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 4
mm² 120
Colour Clear
Sheath PVC
CPR Class -
11150004E
5 x 150mm² SY PVC Steel Braided Multicore Clear
GSWB 4 120 Clear PVC - Get Quote
Description 5 x 150mm² SY PVC Steel Braided Multicore Clear
Armour GSWB
No. Cores 4
mm² 120
Colour Clear
Sheath PVC
CPR Class -
